1200HP SCR Drilling Rig

Fully Functional and Currently Drilling a 20,000’ Well. This rig moves fast, has lots of hook load with a small footprint. You won’t find a deal like this anywhere in the world today. Be sure to scroll down page to see the function video of this rig drilling!

MAST: SUPERIOR 136′ X 650,000# SHL X 18′ MAST, (6) SHEAVE CROWN (1) FASTLINE SHEAVE, FINGER BOARD AND 5,000 PSI KELLY HOSE ● SUBSTRUCTURE: 16′ BOX ON BOX W/ 750,000 SET BACK, CENTER STEEL AND ALL ASSOCIATED SPREADERS, EB STYLE DEADLINE ANCHOR ● DRAWWORKS: NATIONAL 80-UE 1000 HP W/ 752 TRACTION MOTOR, DRILLERS CONTROL AND ELMAGCO BRAKE ● TOP DRIVE: CANRIG 275 Ton TOP DRIVE W/ VFD, DRILLERS CONTROL, TORQUE TRACK AND STRONG BACK ● IRON FLOORHAND: BLOHM AND VOSS 120 ● SCR: OMRON 3X3 PLC W/ TOP DRIVE FEEDER ● ENGINES: (3) MTU 16V 2000 / MARATHON MAGNAMAX 915 KW GENERATORS ● MUD PUMPS: (2) – IDECO-1600 (5M) EA P/B (2) 752 TRACTION MOTORS, CHARGE PUMPS, PULSATION DAMPNERS, MUD GUAGES & LINER WASHER SYSTEM ● MUD TANKS: (3) TANK 1100 BBL PIT SYSTEM ● SHALE SHAKERS: BRANDT KING COBRA VENOM ● WATER TANK: 400 BBL W/ CENTRIFUGAL WATER PUMPS ● DIESEL TANK: 12,000-GAL ROUND SKIDDED W/ FUEL PORCH ● TOP DOGHOUSE: WITH ALL CONTENTS ● TRAVELING BLOCK: OILWELL 350 Ton W/ RAISING LINE BECKET ● ROTARY TABLE: RSB-27-1/2” ● AIR HOIST: (2) RUSHI 5,000# ● TONGS: M/U AND B/O ● PRESSURE CONTROL: KOOMEY 210-GAL 6 STATION CLOSING UNIT W/ REMOTE, CHOKE MANIFOLD – 3″ X 5M ● AUXILIARY EQUIPMENT: SEPERATOR, (2) SULLIVAN PALATEK 30 DG SCREW COMPRESSOR, DRILL LINE SPOOL ¼ FULL DRILL LINE, SCR GRASSHOPPER AND FULL SET OF SUITCASES, LOW PRESSURE WATER LINES AND MISC. HOSES., MUD BUCKET ● PARTS HOUSE: BUILT IN ENDS OF TANK W/ CONTENTS TUBULARS: 12,000 FEET OF 5″ 19.50# R2 II WB W/ 4-1/2” IF CONN. DRILL PIPE

See complete inventory along with additional photos in links below.

Group 1 Photos

Group 2 Photos

Group 3 Photos

Rig Inventory Specs

Message us below to schedule a site inspection or if you have any questions
