Equipment Summary
Price :
Price on Request
Type : Equipment For Sale
Date : September 7, 2023
Make : RAYSAN
Model : RYS-180
Year : 2012
Condition : Un-Used Surplus
Warranty : No
Location :
Uzbekistan
Description
750hp Mobile Drilling Rig, designed for drilling clusters and single wells up to 3000m deep, with a 114mm drilling tool, for drilling second holes from existing and abandoned wells!
The mast winch block is trailered, it includes a trailer chassis, power system, corner box gears, winch, pneumatic auxiliary brake with hydraulic cooling, chain transmission, mast, hydraulic winch, hydraulic and pneumatic systems, ramp, etc.
Rated drilling depth: 3000m （φ114mm DP), 2500m （φ127mm DP）
Max hook load: 1800kN
Winch input power-750l.s (559 kW)
Drawworks input power-750 hp (559 KW)
Mast Height: 35.5 m
The height of the upper working balcony from the floor of the working platform: 17.5m The height of the working platform: 5m Height to the rotor beam: 4.2m Equipment of the hoisting system: 5 × 4 Diameter of the hoisting rope: φ29mm （6 × 19） Hook lifting speed: 0.2-1.3m / s Overall dimensions when moving, m: 24m × 3.2m × 4.8m Environment temperature: -45 ℃ ～ + 50s ℃
Detailed Technical Specifications
